BIO-X

Key Features:

• Modular Design: Facilitates easier local service and maintenance, ensuring consistent uptime.
• Dual CPU System: Guarantees higher reliability and enhanced safety standards for critical infusions.
• European ISO 13485 Manufacturing: Produced according to rigorous European quality management systems for medical devices, ensuring high standards.
• RoHS & CE Qualified: Complies with European directives for environmental protection and safety.
• Clear 3.5-Inch LCD Screen: Provides clear vision of infusion data from up to 5 meters, allowing for easy monitoring.
• User-Friendly Numeric Setting Key: Simplifies parameter adjustments for efficient operation.
• One-Button Night Mode: Designed for patient comfort, providing a quieter environment during nighttime.
• Free Stacking: Single syringe pumps can be freely stacked, optimizing space in busy clinical environments like ICUs, NICUs, and OTs.
• Body-Weight Mode: Satisfies diverse drug dosage requirements in clinical use, enhancing precision.
• Multiple Infusion Modes: Offers Rate Mode, Rate-Time, Rate-VTBI, Time-VTBI, and Body Weight modes to suit various clinical choices.
• High Accuracy: Delivers infusions with an accuracy of ±2%.
• Comprehensive Alarms: Audible and visible alarms for occlusion, low battery, end of infusion, abnormal rate, and more, ensuring patient safety and prompt intervention.
• Adjustable Occlusion Pressure: Features three levels of occlusion pressure (High, Middle, Low) for customizable safety.
• Drug Library: Includes a 20-drug list with drug code display for streamlined drug administration.
• Purge / Bolus Functionality: Supports rapid drug delivery when needed.
• Battery Display: Provides clear indication of battery status.

Technical Specifications:

• Model: BXSP (Single/Double configurations available)
• Syringe Compatibility: 5ml, 10ml, 20ml, 30ml, 50/60ml
• Flow Rate Range (50/60ml Syringe): 0.1 ml/h - 1200 ml/h
• Accuracy: ±2%
• Time Preset: 00:01 - 99:59 (Hour: Min)
• Volume Range: 0 - 9999.9 ml
• KVO Rate: 0.1-1.0 ml/h (adjustable)
• Occlusion Pressure: High, Middle, Low settings
• Battery: Rechargeable Li-ion battery (approx. 4 hours at 5ml/h)
• Power Supply: AC 100-240V, 50/60Hz
• Classification: Class II, Type CF
• Dimensions (BXSP11 Single): 280 mm (L) × 210 mm (W) × 130 mm (H)
• Weight (BXSP11 Single): 2.2 kg
